ELECTRICAL CHARACTERISTIC
Rated Voltage
• Rated Operational Voltage (V AC)	Up to 600V
• Frequency (Hz)	50 / 60Hz

AMF FEATURE
Battery Charger Type	Lead Acid / Nickel Cadmium
DC Voltage	24V DC / 12V DC
AMF Control Wiring / Circuit	YES
Basic Meter Indication	YES

MECHANICAL CHARACTERISTIC
Form Segregation According to IEC 439-2	2B / 3B / 4B
Degree of Protection According to IEC 529	External IP54 / 41 Internal 2X
Surface Protection	Anti Rust Treatment / Epoxy Powder Coating / Oven Baked
Standard Colours	RAL 7032 Other colors upon request
Access	Front and Rear
Cable Entry	Top and Bottom
Ventilation	Air Louvers
Busduct Entry	Upon Request

MATERIAL
Frame Structure Material	EG Sheet
Material Thickness : • Frame Structure Material	2.5mm (Floor Standing) / 1.5mm (Wall Mounted)
• Front Cover	2.5mm (Floor Standing) / 1.5mm (Wall Mounted)
• Side / Rear Cover	2.5mm (Floor Standing) / 1.5mm (Wall Mounted)
• Internal Separation	1.5mm (Floor Standing) / 1.5mm (Wall Mounted)
• Base	Robust C - Channel
• Protection Barrier	Polycarbonate Sheet 2.0mm
